SL412 Technical Data Sheet
Introduction
Application
The SL412 is a slim, discreetly profiled cabinet with wide dispersion at high frequencies.
The four twelve inch speaker configuration provides controlled low-mid focus to reduce
indoor reflection. Its slim design allows for simple wall mounting, suspension, ground
stacking or internal wall fixing. The SL412 can be designed and supplied with custom
colours, grill templates and logos, offering a flexible and truly designer integrated
product. A single horizontal yoke assembly with multiple fixed angles and fixing
locations provides a quick and cost effective solution for simple suspension.
● Slim, discreetly profiled wall mount cabinet
● Wide dispersion at high frequencies, controlled at low-mids to reduce indoor
reflections
● 134dB sustained output, 137dB peak with very high dynamic range
● Simple wall mounting and suspension, ground stacking options
and can be installed internally into walls and surfaces
● These units can be designed and supplied with custom colors, grill templates
and logos, offering a flexible and truly designer integrated product
● A single horizontal yoke assembly with multiple fixed angles and fixing locations,
provides a quick and cost effective solution for simple suspension options
● The SL412i & SL2.15i are identical in performance and finish as the existing
SL412 & SL2.15, except they do not incorporate the fixed handles for touring
and presentation use. The ‘I’ version is designed for fixed installation use with
the same existing mounting and flyware fixings
Custom designed as an aesthetically – easily
integratable high performance unit
for multi-tasking installation projects
of recorded and live music performance
● Fixed installation
● Nightclubs
● Multi-use venues
● Large bars
System Acoustic Perfomance
Max SPL Long-term 134dB
Max SPL Peak 140dB
-3dB Response 70Hz to 22kHz
-10dB Response 58Hz to 30kHz
High Frequency Section
Acoustic Design Horn Loaded
High Horn Coverage Horizontal /
Vertical
110° x 40°
Rotatable Horn NO
High Frequency Amplifier Requirement 100W
Throat Exit Diameter / Diaphragm Size 1.4" / 3"
Diaphragm Material Nitride Titanium
Magnet Type Neodymium
Mid Range Section
Acoustic Design Horn Loaded
Mid Horn Coverage Horizontal / Vertical 110° x 40°
Rotatable Horn NO
Midrange Amplifier Requirement 200W
Woofer Size / Voice Coil Diameter /
Design
8" / 3.0" /
Trans Coil
Diaphragm Material Epoxy Reinforced Cellulose
Magnet Type Neodymium
Low Frequency Section
Acoustic Design Front Loaded, Bass Reflex
Low Frequenzy Amplifier
Requirement
1000W
Number of Drivers 4
Woofer Size / Voice Coil Diameter /
Design
12" / 3" /
Inside Outside
Magnet Type Neodymium and Ferrite
Speaker Input
Speaker Input AP6
Cabinet
Cabinet Material Baltic birch
Handles 2
Flyware 20x M10 mounting points
Color "Orange peeled"
Matt Black or any RAL
Physical Dimensions
Height 670 mm (26.38")
Width 1080 mm (42.52")
Depth 300 mm (11.81")
Weight 60 kg (132.28lbs
